A chemical manufacturing customer needed a solution for transferring chemicals within their facility, so we built this Blackmer SMVP Series sliding vane pump. The close-coupled mag-drive pump is made of stainless steel and powered by a WEG motor, mounted on a powder-coated steel double-bent base. We chose the Blackmer SMVP because the seal-less magnetic coupling provides […]
Do you need custom fabrication work? We helped fabricate this custom Venturi out of 304 stainless steel per our customer’s drawing and specification. We can help build custom components or use standard part numbered components, which is what we did here. With the help of Dixon Valve and our many other suppliers, we can build a […]
We built this simple filtration hand cart to be moved around a power plant. The cart utilized a 20″ Shelco Filters filter housing and a Global Filter 1-micron meltblown cartridge filter. A 1″ Wilden aluminum air-operated double diaphragm pump pumps through the filter. We used a Continental Contitech Fabchem UHMW hose to connect the pump […]
This custom portable air-operated double diaphragm pump cart was built for a food and packaging manufacturer. We mounted a Wilden Hygienic Series 1″ pump on a portable stainless steel cart that we fabricated. The cart includes a RTi-PBE filter regulator, Dixon Valve air shut-off valve, Tudertechnica Glidetech product hoses and a Continental Contitech air hose. […]
We recently installed a new hose crimper at our Cleveland location. This enables us to hydrostatically test our hose assemblies in-house and offer on-site hydrostatic hose testing services. We wanted the ability to test hoses in-house and on-site to duplicate our other locations’ hose-manufacturing capabilities. Here we built a 500 PSI hydrostatic hose tester with […]
Made to pump carrots, this 4″ Cornell Pump Company food processing pump assembly is built on a custom stainless steel frame and is powered by a 7.5 HP Toshiba motor. The 4″ frame-mounted pump can pump up to 825 GPM. Not pictured: Hydro-Transport product tank that we built to help move product into the pump. […]
We built two custom filtration skids, each featuring two Wilden P200 AODD pumps, two FTI housings, two Orange Research differential pressure gauges, a Tudertechnica hose for vibration dampening, Dixon ball valves and a wall-mounted control panel built by our Michigan branch. The skids, which are used to filter an acid used in the pickling process, […]
During food processing, the product is often transferred and cleaned using water. It is common to see a Hydrosieve in the initial cleaning or water extraction phase of the process. Anderson Process helped design and build these all-stainless-steel units to help process peas. The wedge wire screen is 60″ wide, with .125″-wide slot openings. The product falls […]
We mounted an FTI (Filter Technology Incorporated) stainless steel filter housing on a stainless-steel fabricated cart. This allows the filter cart to be moved around the plant during the manufacturing of paint. The customer wanted the filter housing mounted on an angle to make changing the filter bags easier.
Built to filter cooling water in a cooling tower basin, this filter skid features a Xylem (Goulds Water Technology) E-SH pump, Clear Blue multi-round bag housing, and Dixon butterfly valves. We mounted the equipment on a fabricated c-channel base plate with lifting lugs and grouting holes. The equipment connected to welded SCH40 carbon steel piping.
We built multiple sprinkler stands that will be used at a loading/unloading terminal that handles a multitude of different materials (limestone, taconite, etc.). The stands will be used with Nelson Irrigation Corporation Big Gun sprinklers, which will deliver 350 GPM in a 400’ diameter circle – or partial circle, if needed. The application will also […]
